Input voltage : 100 - 240 VAC
Input frequency : 50/60 Hz
Input current : 1.5 A
Input connector : UK (Type G)
Output voltage : 48 VDC
Output current : 1.3 A
Output connector : 4pin, 3 mm pitch
Read more| Input voltage | 100-240 VAC |
| Input frequency | 50/60 Hz |
| Input current | 1.5 A |
| Input connector | UK (Type G) |
| Output voltage | 48 VDC |
| Output current | 1.3 A |
| Output connector | 4pin, 3 mm pitch |
| Weight | 380 g |
| Input voltage range | 90 - 264 VAC |
| Input frequency range | 47 - 63 Hz |
| Maximum input inrush current | 50 A |
| Output voltage maximum deviation | 45.6 - 50.4 VDC |
| Short circuit protection | ✓ |
| HIPOT (dielectric withstand test) | Primary to Secondary: 4000 VDC |
| MTBF | 50000 h |
| Certification | Safety: IEC/EN 61558-1:2005+A1:2009, IEC/EN 61558-2-16:2009+A1:2013 (CB Scheme) EMC: EN 55032:2012+AC:2013, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 55024:2010+A1:2015 |
